Promag MF7 – MIFARE® UID Reader

  • Reading distance: up to 50mm
  • Frequency: 13.56 MHz
  • Read MIFARE UltraLight® and MF1 Standard cards
  • 3-in-1 interface (Wiegand, MSR ABA TK2 and RS232)
  • Fast data transfer
  • Weather resistant
  • High data integrity
  • Easy to install
  • Available installed on metal surface
SKU: Promag MF7 - MIFARE® UID Reader Categories: , Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

Description

Features

  • Reading distance: up to 50mm
  • Frequency: 13.56 MHz
  • Read MIFARE UltraLight® and MF1 Standard cards
  • 3-in-1 interface (Wiegand, MSR ABA TK2 and RS232)
  • Fast data transfer
  • Weather resistant
  • High data integrity
  • Easy to install
  • Available installed on metal surface

Specifications

  • Interface:
    • Wiegand
    • MSR ABA Track2
    • RS232
    • Or special customized specifications.
  • Typical Maximum reading distance:Up to 50mm at 5~12V with MIFARE card In ideal conditions.
  • Electrical: 5~18 Volts regulated DC at 200 mA typical. A linear regulator is recommended.
  • Frequency: 13.56MHz standard
  • Transponder: Read Only (for Unique Serial Number / Unique Identifier)
  • Read MIFARE standard cards for 1024/4096 byte and MIFARE UltraLight cards of EEPROM size 512bit for ISO 14443A
  • External control Audio / Visual Indication: Internal LED and Buzzer
  • Dimensions: 83 (L) x 47 (W)x 16(H) mm
  • Housing material: ABS
  • Environmental:
    • Operating temperature Range: -10 to 60 Deg C.
    • Operating relative Humidity: 10 ~ 90%.

Applications

  • Access control
  • Security system
  • ID card for admission control
  • Personal Identification
