Configuration: | Desktop |
Paper Source: | Three optional tables (choose one): 1. Manual Bypass Cut Sheet Feed Table 2. One Roll Tray Table With Manual Bypass Tray 3. Two Roll Tray Table With Manual Bypass Tray |
Optional Paper Cassette Tray: | The one and two roll tray table options each permit the addition of the Paper Cassette Tray which automatically feeds up to 12″ x 18″ cut sheet paper. |
Warm-up Time: | Less than 2 minutes |
First Copy: | 22 seconds (D size) |
Copying Speed: | 4 cpm/ppm (D size); 2 cpm/ppm (E size) |
Resolution: | 600 dpi x 600 dpi |
Grayscales: | 256 levels |
Grayscale Printing: | 2 levels |
Reduction/Enlargement: | 16 presets: Zoom 25% to 200% in 0.1% increments; 200% to 400% in 0.2% increments |
Multiple Copies: | 1–20 |
Cutting Method: | Synchronized cut, preset cut, variable cut |
Memory Capacity: | 80 MB; optional hard drive: 10 GB |
Original/Copy Size: | Maximum: 36″ x 141″; Minimum: 8 1⁄2 ” x 5 1⁄2 “; 36″ x 78” bypass Copy Exits: Top tray, Standard; Rear/Bottom, with Optional Roll Feed Table |
Original Exits: | Top; Rear Straight Path |
Power Source: | 120V/60Hz; 15A |
Dimensions (WxDxH): | 42.5″ x 25″ x 23″ |
Weight: | 218 lbs. (Copier only) |
Copier Options: | Cut Sheet Feed Table One Roll Paper Tray Table Two Roll Paper Tray Table Universal Paper Cassette (Only with 1 or 2 Roll Paper Tray Table) Hard Disk Drive (Required for Sorting, Stamping and Image Overlay) Stamp Board Roll Holders |
Print Controller RW-240 (optional) | |
---|---|
PC Server Specifications | |
Controller Type: | External PC Server (Note: Server not included, must be purchased separately from an appropriate vendor) |
PC System Requirements | |
Operating System: | Windows® 2000 Professional SP3 or Windows XP Professional SP1 |
Processor: | Pentium 4, 1 GHz |
PCI: | 2.0 or higher x 1 slot (with 3.3 V or 5V auto adaptive) |
System Memory: | At least 512 MB RAM for scanning or drawing to maximum size |
Hard Drive: | At least 10 GB memory |
Network Interface: | 10/100 BaseT Ethernet, TCP/IP configuration |
Monitor: | At least 1024 x 768 pixels resolution |
Maximum Speed: | 4 ppm (D size), 2 ppm (E size) |
Network Protocol: | TCP/IP, IPX/SPX, lpr/lpq, HTML, SMB |
PC Interface Slot: | PCI 2.0 or higher x 1 slot (with 3.3V or 5V auto adaptive) Max. Load 5A |
Print Controller: | Supported Output File Formats: HP-GL, HP-GL2, HP-RTL, TIFF, Calcomp 906/907, WMF, BMP, CALS, T6X, CIT, PCX. |
Optional: | PostScript 3 (for PDF printing and scanning), CGM (Computer Graphics Metafile) |
Unix Support: | Redhat Linux 6.x–7.1; HP-UX 10.x/11.x; Sun Solaris 2.67.x/8.x; SCO Open Server 5.x (up to 5.06) |
Print Controller Features: | Account Tracking Auto Paper Select Border Setting Entry Collation Help Image Rotation Limitless Paper Feed Locked Print Magnification Media Selection Mirror image Multiple copy Output Tray Select Pen Settings/Stamping Roll/Media Select Status Monitor Sample Print |
Scanning (Optional) | |
---|---|
Controller Type: | External PC Server (Same as for Print Controller) |
Maximum Speed: | 4ppm (D size) |
Resolution: | 150-600 dpi (1200 dpi with enhancement) |
Scan Size: | 8.26“ x 7.16” to 35.98“ x 236“ |
File Formats: | TIFF Single and Multi page (uncompressed/G3/G4), T6X, BMP, RLC, HP-RTL, PCX, CALS 1&2, PDF (Single and Multi-Page). |
Reading Area Setting: | Auto, Fixed, User Defined |
Continuous Input: | Batch Scanning, Scan to File with Autoname, Save Multiple Page Document in One File (PDF or TIFF) |
Scanning Modes: | Single Copy, Set copy, Batch Scanning, Archiving, Integrated Editor |
Scanner Software: | SCANTOOL |
Controller Options: | RW-240 Controller Controller Interface PCB Type 240 Scan Option PostScript 3 (Emulation) CGM (Computer Graphics Metafile) |
