Specifications:

Configuration Console
Printing Process Single Laser Beam Scanning & Electrophotographic printing
Dimensions (W x D x H) 24.8″(W) x 25.7″(D) x 27.9″(H)
Weight 143 lbs.
Standard Paper Capacity 550 sheets x 2 trays and 100-sheet bypass tray
Optional Paper Capacity 550 sheets x 2 trays or 2000 sheet large capacity tray (LCT)
Paper Size 5.5″ x 8.5″ to 11″ x 17″/ A6 to A3
Paper Weight 16 – 28 lb. Bond/60 – 105g/m² (Tray 1 and Duplex)
14 – 42 lb. Bond/52 – 157g/m² (Tray 2 and Bypass)
Reduction Ratios 25%, 50%, 65%, 73%, 78%, 85%, 93%, 100%
Enlargement Ratios 121%, 129%, 155%, 200%, 400%
Zoom 25% to 400% in 1% increments
Standard Features Auto Magnification, Auto Paper Select, Auto Tray Switch, Center/Border Erase, Chapters, Full-Color VGA Touch Screen Control Panel, Combine Mode, Cover Insertion, Date Stamp, Directional Magnification, Electronic/Rotate Sorting, English Pre-Set Stamps, Negative/ Positive, OHP Slip Sheet, Page Number Stamp, 10 Job Programs, 500 User Codes
Document Feeding Optional 50-sheet ARDF
Optional Features with HDD Background Numbering, Booklet/Magazine Copy, Document Server (3000 file capacity) and User stamps
Security Features S/MIME, IPsec Communication, Locked Print Password Encryption, Encrypt Address Book, SSL Secure Socket Layer, User Authentication, SNMP v3, Encryption of Password PDF, Encrypted PDF
Toner Dry, Dual Component
System Memory (std/max.) 512/1024 MB RAM
Hard Disk Drive 40 GB optional
Copy Resolution 600 x 600 dpi
Grayscale 256 levels
Exposure Adjustment Manual & Automatic
Scanning Element Flatbed with Moving CCD Array Image Sensor
Quantity Indicator Up to 999
Original Type Book/Sheet
Maximum Original Size Up to 11″ x 17″
Copy Size 5.5″ x 8.5″ to 11″ x 17″
Copy Type Plain Paper, Transparencies, Envelopes, Cardstock, Recycled
Warm-Up Time 14 seconds
First Copy Speed 4.5 seconds
Continuous Copying Speed 30 copies/minute (LTR)
Recovery Time 10 seconds (from Auto Off)
Power Source 120V/60Hz/12A

Printer Specifications:

Print Speed 30 ppm
Standard Interfaces 10/100BaseTX, USB 2.0
Optional Interfaces IEEE 802.11a/b/g Wireless LAN Bluetooth IEEE 1284
Memory Capacity Gigabit Ethernet Shared with copier
Network Protocol TCP/IP, IPX/SPX, AppleTalk
Network Operating Systems Windows Vista/2000/ME/XP/Server 2003, Systems Netware 3.12, 3.2, 4.1, 4.11, 5.0, 5.1, 6.0, 6.5, Unix; Sun Solaris, HP-UX, SCO OpenServer, Red Hat Linux, IBM AIX, Mac OS 8.6 – 9.2x, OS X 10.1 or later, SAP R/3, NDPS Gateway, IBM iSeries/AS/ 400® using OS/400 Host Print Transform, Citrix Metaframe Mac 8.6-9.2x, 10.1+, SAP R/3, NDPS
Utilities SmartDeviceMonitor, Web SmartDeviceMonitor, DeskTopBinder, Web Image Monitor
Page Description Languages PCL 5e/6 emulation RPCS Adobe PostScript 3 (optional)
Print Resolution Up to 600 dpi (2400 x 600 dpi with smoothing)
CPU RM7035C 533 MHz
Grayscale 256 Levels
Fonts for PCL5e/6 35 Intellifonts, 10 TrueType Fonts, 1 Bitmap, 13 International Fonts
Fonts for PS3 136 PostScript Fonts
Standard Features Sample/Locked/Hold/Stored Print

Scanner Specifications:

Scanning Speed B&W/Color: Embedded Scanning: 52 ipm (@ 200 dpi)
Grayscale 256 Levels
Scan Area Up to 11″ x 17″
Interface (standard) 10/100 BaseTX
Interface (optional) IEEE 802.11a/b/g Wireless LAN, Gigabit Ethernet
Protocol TCP/IP, SMTP, POP 3, SMB, FTP, NCP, LDAP
Memory Capacity Shared with Copier
File Types Single and multi-page TIFF/PDF, High Compression PDF, Single-page JPEG
Scanning Resolution 1200 dpi

Fax Specifications:

Circuit PSTN, PBX
Resolution 200 x 200/100 dpi 400 x 400 dpi (optional)
Compression Method MH, MR, MMR, JBIG
Scanning Speed 0.40 seconds (LEF)
Modem Speed 33.6 Kbps with Auto Fallback
Transmission Speed G3: 3 seconds per page (MMR Compression) G3: 2 seconds per page (JBIG Compression)
Memory 4 MB standard/28 MB maximum
Std./Max. Auto Dials 2,000 (with HDD)
Group Dials 100 (max. 500 numbers per group)
Compatibility ITU-T G3
ID Code Programming 4 digits
User Function Key 3 Keys
Standard Features Book Transmission, Dual Access, Duplex Reception, Image Rotation, 1 Hour Backup, LAN-FAX Compatibility, Internet Faxing (T.37) IP Faxing (T.38) Fax Forwarding to e-mail/HDD/Folder
Optional Features Simultaneous Operation of up to 3 Lines (G3 x 3)
